LITTLEBIT®
Littlebit®
Insertable External/Internal Grooving
Littlebit®
Insertable Parting
Littlebit®
Insertable Internal Threading
LITTLEBIT®
Insertable External/Internal Grooving
Shown: Insert in Right Hand Toolholder
- For internal diameters of 1.250" and larger
- For Depths of Cut 1-1/2 to 3 times groove width
- Groove widths .004" - .125" in .001" increments
- Cuts to within 1/16" of shoulder. To work against a shoulder, see GROOVE 'N TURN® grooving tools.
- CNC, Swiss, Conventional and round toolholders of various sizes and orientations available.
LITTLEBIT®
Insertable Parting
Shown: Insert in Right Hand Toolholder
- For diameters 1" and smaller
- Parting widths .025", .045", .062", .085", .115"
- Narrow widths reduce material loss and part deflection.
- Perfect for thin wall tubing, precious metals and small diameter parts.
- CNC, Swiss, Conventional and round toolholders of various sizes and orientations available.
- Geometries including lead angles, top rakes, chip breakers, clearance angles and custom forms can be provided.
LITTLEBIT®
Insertable Internal Threading
Shown: Insert in Right hand Toolholder
- 60° profile for external and internal threading
- 8 Threads Per Inch and greater
- Sharp corner or .002" nose radius
- For internal diameters of 1.250" and larger
- CNC, Swiss, Conventional and round toolholders of various sizes and orientations available.
- Geometries including lead angles, top rakes, chip breakers, clearance angles and custom forms can be provided.
